Limited Carl Fogarty Edition

2002 Ducati Monster

Price: US $5,500.00
Item location: Catoosa, Oklahoma, United States
Make: Ducati
Model: Monster
SubModel: S4 Carl Fogarty Edition #135
Year: 2002
Mileage: 8,640
VIN: ZDM1RB8S12B007496
Color: Italian Tri-color
Engine size: 916
Vehicle Title: Clear
Description

Long live the King!The S4 Fogarty. truly an instant classic. is a tribute to the amazing career of a four-time WSBK champion. A singular bike for the most discerning enthusiasts. Only 300 were built and only 75 shipped to the U. SState-of-the-art components and accessories transform a standard M S4 into a true collectible and missile on the track. Full racing exhaust by Termignoni. oversized open breather and high performance computer chip are part of the performance package that go along with the custom tri-colour paint and the extraordinary amount of carbon fiber body and engine work.

Within the M. Y. 2002 Monster range. the Monster S4 has a story of its own. The MS4 represents an extreme evolution and refinement of the Monster concept-a concept that scores of enthusiasts around the world have come to admire and respect. To put is simply. the Monster S4 is not a variant of the Monster 900 Special. but an entirely new motorcycle with an entirely new mission.

However. because of the layout of components. technical content. overall performance and rational approach. the Monster S4 has remained true to the original Monster styling concept.

In order to define each detail in the most rational and accurate way. Ducati used for the first time advanced Unigraphics software for computerized 3D modeling. Such highly sophisticated computer technology enabled accurate structural and functional testing prior to the construction of the operating prototype. As a result. development time was dramatically reduced and the project was totally optimized before implementation.

The Monster S4 stems from a perfect symbiosis of the robust ST4 frame. the 916 cc Desmoquattro twin-cylinder engine with modified head and lowered exhaust cam and a new rear suspension with a aluminum swingarm. which was sized to obtain a 1440 mm wheelbase.

It turns out 101 Hp. with 66. 5 ft. lbs. peak torque and an extraordinary output curve throughout an incredibly broad rpm range.

The Monster S4 Fogarty not only offers unbelievable acceleration and pickup. with its lean 414 lbs. . but also unprecedented handling. It sits 20 mm higher than other Monsters in order to provide the Ground Clearance needed for riders using its astonishing cornering ability to the fullest.

Make Model

Ducati Monster S4 Foggy

Year

2002

Engine

Four stroke. 90°“L”twin cylinder. DOHC. desmodromic 4 valve per cylinder.

Capacity

916Bore x Stroke94 x 66 mmCooling SystemLiquid cooled. ompression Ratio11:1LubricationWet sumpEngine OilSemi-Synthetic. 10W/40

Induction

Marelli electronic fuel injection. 50mm throttle body

Ignition

Analogue CDI (Capacitive Discharge Ign with racing chip)Spark PlugChampion. RA59GCStartingElectric

Max Power

118 hp / 74 kW @  8750 rpm

Max Torque

92 Nm / 9. 3 kgf-m @ 7000 rpmClutchSystem: Dry multiplate with hydraulic control

Transmission

6 SpeedFinal DriveChainFrameTubular steel trellis

Front Suspension

Showa 43mm upside-down fully adjustable fork. Front Wheel Travel120 mm / 4. 7 in

Rear Suspension

Progressive linkage with fully adjustable Sachs monoshock with piggy back aluminum swing arm. Rear Wheel Travel148 mm / 5. 8 in

Front Brakes

2x 320mm discs 4 piston calipers (Brembo)

Rear Brakes

Single 245mm disc  2 piston caliper (Brembo)

Front Tyre

120/70 ZR17

Rear Tyre

180/55 ZR17Rake24°Trail96 mmDimensionsLength 2121 mmWidth   885 mmHeight 1222 mmWheelbase1440 mm / 56. 7 inSeat Height803 mm / 31. 6 in

Dry Weight

193 kg / 425. 5 lbs

Fuel Capacity

15 Litres / 4. 0 galReserve3. 5 Litres

Consumption Average

18. 7 km/lit

Standing ? Mile

11. 1 sec  /  198 km/h

Top Speed

239 km/h
